1653nm DFB Single Mode Fiber Laser Module adopts butterfly semiconductor laser chip, professional design of driving circuit and TEC control to ensure the safe operation of laser, stable output power and spectrum.
1653nm DFB Single Mode Fiber Laser Module adopts butterfly semiconductor laser chip, professional design of driving circuit and TEC control to ensure the safe operation of laser, stable output power and spectrum.
High output power;
Power and spectral stability;
Benchtop or Module package.
Gas sensing;
Fiber laser;
Research on nonlinear optics.
| Parameters | Unit | Values | Notes |
| Operating wavelength | nm | 1653.7nm | Customizable |
| Output power | mW | 10/40 | Customizable |
|
Power instability (Short-term 15mins) |
dB | ≤±0.02 | |
|
Power instability (Long-term 8hours) |
dB | ≤±0.05 | |
| Connector | - | FC/APC | |
| Fiber type | - | SMF-28/PM1550 | |
| Dimensions | mm | 260(W)×280(D)×120(H) | Benchtop |
| 150(W)×125(D)×20(H) | Module | ||
| Power supply | V | AC 110~240V | Benchtop |
| DC 5V/4A | Module | ||
| Communication interface | - | DB9 Female(RS232) | |
| Operating temperature | ℃ | -20 ~ +65 | |
| Storage temperature | ℃ | -40 ~ +85 |
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
A: We have 1653nm, CWDM wavelength.
Q: What is the requirement for the output power?A: We have 10mW and 40mW, we can also customize according to your requirement.
Q: About the package dimension, do you have any requirement?A: We have the module type and benchtop for choice.
