1064nm Fiber Laser Module For Seed Source In MOPA System

1064nm Fiber Laser Module For Seed Source In MOPA System can be used as seed laser of high power laser,1060nm band fiber devices.

Send Inquiry

Product Description

1. Introduction of 1064nm Fiber Laser Module For Seed Source In MOPA System

This laser adopts butterfly semiconductor laser chip, professional design of driving circuit and TEC control to ensure the safe operation of laser, stable output power and spectrum. It can be used as seed laser of high power laser,1060nm band fiber devices.

2. Feature of 1064nm Fiber Laser Module For Seed Source In MOPA System

High output power;

Power and spectral stability;

Benchtop or Module package.

3. Application of 1064nm Fiber Laser Module For Seed Source In MOPA System

Seed light source;

Fiber laser;

Research on nonlinear optics.

4. Optical-Electrical Characteristic of 1064nm Fiber Laser Module For Seed Source In MOPA System

Parameters Unit Values Notes
Operating wavelength nm 1030/1060/1064/1070 Customizable
Output power mW 100/200/300 Customizable
Power instability
(Short-term 15mins)
dB ≤±0.02
Power instability
(Long-term 8hours)
dB ≤±0.05
Connector - FC/APC
Fiber type - Hi1060/PM980
Dimensions mm 260(W)×280(D)×120(H) Benchtop
150(W)×125(D)×20(H) Module
Power supply V AC 110~240V Benchtop
DC 5V/4A Module
Communication interface - DB9  Female(RS232)
Operating temperature -20 ~ +65
Storage temperature -40 ~ +85

5. Typical Characteristic Curve of 1064nm Fiber Laser Module For Seed Source In MOPA System

6. Deliver,Shipping And Serving of 1064nm Fiber Laser Module For Seed Source In MOPA System

All products have been tested before shipping out;

All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)

We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);

If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;

If the items are defective, please notify us within 3 days of delivery;

Any items must be returned in their original condition to qualify for a refund or replacement;

The buyer is responsible for all the shipping cost incurred.

7. FAQ

Q: What is the wavelength would you like?

A: We have 1030nm 1060nm 1064nm and 1070nm.

Q: What is the requirement for the output power?

A: We have 200mW and 400mW, we can also customize according to your requirement.

Q: About the package dimension, do you have any requirement?

A: We have the module type and benchtop for choice.
