An optical fiber sensor is a sensor that converts the state of the measured object into a measurable light signal. The working principle of the optical fiber sensor is to send the incident light beam from the light source into the modulator through the optical fiber. The interaction between the modulator and the external measured parameters determines the optical properties of the light, such as the intensity, wavelength, frequency, phase, polarization state, etc. It changes and becomes a modulated optical signal, which is then sent to the optoelectronic device through the optical fiber and passed through the demodulator to obtain the measured parameters. During the whole process, the light beam is introduced through the optical fiber, passes through the modulator, and then emitted. The role of the optical fiber is first to transmit the light beam, and secondly to act as an optical modulator.
Fiber amplifier in a fiber optic data link, the amplification process that occurs over a very long transmission fiber.
A diode laser in which the light generated is coupled into an optical fiber.
Some laser applications require the laser to have a very narrow linewidth, that is, a narrow spectrum. Narrow linewidth lasers refer to single-frequency lasers, that is, there is a resonant cavity mode in the laser value, and the phase noise is very low, so the spectral purity is very high. Typically such lasers have very low intensity noise.
The gain medium of an optical amplifier can only achieve a limited gain. One approach achieves higher gain by geometrically setting up light so that it passes through multiple channels as it passes through the amplifier, known as a multipass amplifier. The simplest is a two-pass amplifier, where the beam passes through the crystal twice, usually with exactly or nearly opposite directions of propagation.
Time-domain OCT is mainly composed of Michelson interferometers. The light emitted by the light source is divided into two beams after passing through the coupler, and enters the sample arm and the reference arm of the Michelson interferometer respectively.
