808nm 100W Multi-mode LD Fiber Coupled Diode Laser is high output power and high coupling efficiency in the industry. With high output power of 100W, 808nm laser diode provides super intense and CW laser light source in laser pumping source, medical, material processing and printing etc. Customized version and systems designed for different fibers are available.
808nm 100W Multi-mode LD Fiber Coupled Diode Laser is high output power and high coupling efficiency in the industry. With high output power of 100W, 808nm laser diode provides super intense and CW laser light source in laser pumping source, medical, material processing and printing etc. Customized version and systems designed for different fibers are available.
808nm 100W Multi-mode LD Fiber Coupled Diode Laser is high output power and high coupling efficiency in the industry. With high output power of 100W, 808nm laser diode provides super intense and CW laser light source in laser pumping source, medical, material processing and printing etc. Customized version and systems designed for different fibers are available.
808nm wavelength;
100W output power;
200/220μm 0.22NA Fiber;
High brightness;
RoHS Compliance.
Medical care;
Printing;
Material processing;
Pump source.
| Parameter | Symbol | Min. | Typ. | Max. | Unit |
| Operating output power | Pout | - | 100 | - | W |
| Range of available wavelength | λ | 805 | 808 | 811 | nm |
| Spectral width @ FWHM | Δλ | - | 4.0 | - | nm |
| Threshold current | Ith | - | 1.0 | 1.5 | A |
| Operating current at Pout | IOP | - | 9.5 | 10.0 | A |
| Operating voltage at Pout | VOP | - | 27.0 | - | V |
| Power conversion efficiency | - | - | 40 | - | % |
| Wavelength temperature coefficient | Δλ/ΔT | - | 0.3 | - | nm/℃ |
| Slope efficiency | η | - | 13.0 | - | W/A |
| Fiber bend radius | r | 37.5 | - | - | mm |
| Fiber core/cladding diameter | DCOR | - | 200/220 | - | µm/µm |
| Fiber buffer diameter | DBUF | - | 320 | - | µm |
| Fiber numerical aperture | NA | - | 0.22 | - | - |
| Beam numerical aperture(90% power) | NA | - | 0.18 | - | - |
| Fiber length | Lf | - | 1.5 | - | m |
| Connector type | - | Null or SMA905 | - | ||
All products have been tested before shipping out;
All products have 1-3 years warranty.(After the quality guarantee period began to charge appropriate maintenance service fee.)
We appreciate your business and offer an instant 7 days return policy. (7 days after receiving the items);
If the items you purchase from our store are not of perfected quality, that is they don‘t work electronically to manufacturers specifications, simply return them to us for replacement or refund;
If the items are defective, please notify us within 3 days of delivery;
Any items must be returned in their original condition to qualify for a refund or replacement;
The buyer is responsible for all the shipping cost incurred.
A: We have 793nm 808nm 915nm 975nm laser diode.
Q: What is the requirement for the output power?A: Box optronics can customize according to your requirements.
