1310nm 10dBm SOA Semiconductor Optical Amplifier SM Butterfly

The 1310nm 10dBm SOA Semiconductor Optical Amplifier SM Butterfly is designed by using a high quality angled SOA chip and a TEC which can assure a stable amplified output for a large dynamic input signal. The devices are available in a standard, 14-pin butterfly package at the 1310nm and 1550nm bands. The SOA devices have high optical gain, high saturation output power, low polarization dependent loss, low noise figure and broad wavelength range. We have options of optical isolators for input and/or output side as well as output fibers of SM fibers, PM fibers and other special fibers per customer specifications. The products are Telcordia GR-468 qualified, and in compliance with RoHS requirement.

The 1310nm 10dBm SOA Semiconductor Optical Amplifier SM Butterfly is designed by using a high quality angled SOA chip and a TEC which can assure a stable amplified output for a large dynamic input signal. The devices are available in a standard, 14-pin butterfly package at the 1310nm and 1550nm bands. The SOA devices have high optical gain, high saturation output power, low polarization dependent loss, low noise figure and broad wavelength range. We have options of optical isolators for input and/or output side as well as output fibers of SM fibers, PM fibers and other special fibers per customer specifications. The products are Telcordia GR-468 qualified, and in compliance with RoHS requirement.

Traveling-wave MQW design;

CW or pulsed operation;

Single mode input/output ;

Low chip-to-fiber coupling loss;

Built-in thermistor and TEC;

Hermetic butterfly package;

Optional FC/APC connectors.

Loss compensation for fiber optic connection and switch;

WDM fiber optic networks;

100G fiber optic data center.

•

• PIN	DESIGNATIONS	PIN	DESIGNATIONS
  1	TEC（+）	14	TEC（-）
  2	Thermistor	13	Case Ground
  3	PD Anode	12	NC
  4	PD Cathode	11	SLD Cathode(-)
  5	Thermistor	10	SLD Anode(+)
  6	NC	9	NC
  7	NC	8	NC
